LYJ-90
| Model | LYJ-90 | |
|---|---|---|
| Capacity | Round bar● | Φ10-90mm |
| Square bar■ | Φ10-85mm | |
| Round tube○ | Φ10-90mm | |
| Square tube□ | Φ10-85mm | |
| Saw Head spindle | TCT Carbide tipped sawblade type | Φ315*2.25t mm |
| HSS high-speed steel sawblade type | Φ315*2.0t-3.0t mm | |
| Sawblade rotation speed | 12-180rpm | |
| Chip removal | Steel brush disc | |
| Motor | Spindle driving pressure | 7.5kw/4p |
| AC Servo motor(Saw Head) | 2kw | |
| AC Servo motor(GFC) | 1kw | |
| Hydraulic pump motor | 2.25kw/4p | |
| Coolant pump motor | 0.19kw/2p | |
| Hydraulic Device | Work operating pressure | 70kg/cm2(7MPa) |
| Tank capacity | 90L | |
| Pneumatic Device | Operating air pressure | 4-6kg/cm2(0.4-0.6MPa) |
| Machine Dimension-Weight | Dimension(L*W*H) | 6565*1772*1735mm |
| Weight(main body) | 2700kg | |
| Loading magazine | 1350kg | |
- Automatic feeding device
- Automatic lubricating device
- Auger-type chip conveyor
- Mist cooling device
- Coolant pump device
- Heat exchanger of electrical cabinet
- Halogen working lamp
